ROEMHELD North America proudly introduces the new Flexline R Rapid Traveling Clamp System, a heavy-duty solution engineered for fast, safe, and fully automatic die clamping on press rams. Designed for tough industrial environments and frequent die changes, the Flexline R traveling clamps combine precision, strength, and configurability to help press operators dramatically cut setup times and boost uptime.
Built on the proven Flexline platform, the Flexline R system features a reinforced stainless steel drive chain and sensor components, high-performance hydraulic clamp cylinders, and advanced sensor technology to ensure safe, reliable clamping—even under the most demanding conditions.
Flexline R —A Smarter, Stronger Traveling Clamp
Flexline R System delivers clear advantages:
-
Higher Clamping Force: Up to 104 kN at 400 bar or 100 kN at 245 bar
-
More Durable Build: Stainless steel pull-push chain and die sensor bracket.
-
Integrated Hydraulic & Electrical Lines: Eliminates cable clutter and fragile external hoses
-
Smarter Safety Features: IP65-rated electrical connectors, inductive and magnetic sensors for multi-point position feedback, and a manual emergency release
-
Configurable & Compact: Available with multiple cylinder types, travel lengths, and T-slot compatibility—all in a low-profile, lightweight design
-
Global Compatibility: available with optional 24V direct current drive motor
"Flexline R was built to outperform our competitors in every category—, compatibility, flexibility, safety, and reliability," said Brent Stille, QDC Product Manager, ROEMHELD North America. “This is a must-have system for press shops looking to automate and improve OEE while protecting their operators and dies.”
You can download the image material in print quality here https://www.auchkomm.com/django-files/pressemeldungen/zips/ROEMHELD_PR_1-2025_Flexline_R_2025-4-29.zip
The electro-mechanical driven push chain moves the clamping element attached to the Flexline-R rapid-clamping system automatically from the parking position to the clamping position at the clamping edge and then back to the parking position.
The T-slot of the machine serves as the guide for the push chain and clamping element. The push chain also serves as the energy chain for accommodating the hydraulic and electric lines of the clamping element.
The drive motor for the Flexline-R rapid-clamping system can be selected in a low voltage version with 24 volts (Green Edition).
Advantages
- 24 volts are available at every press worldwide
- Safe extra-low voltage instead of alternating current at the press ram
- Simple project planning and installation for press manufacturers
- Ideally suited for new installations as well as retrofits
